Mount arrow rest to the bow utilizing theīows equipped with this slot can utilize the rest’s Posi- Lock feature to locate the arrow rest securely into position. Set Draw weight: Adjust draw weight to the desired level by turning the limb.
Draw camtwist install#
Install the arrow rest carefully following the instructions for the rest. Recheck steps 5, 6 and 7 in sequence until everything is correct.ĩ. Timing is adjusted by either twisting or untwisting one or both of the cables until cams are synchronized.Ĩ.
Twist or untwist the control cable to adjust the upper cam so that the string contacts the flat correctly.Ĭhecking timing for bows equipped with a twin cam system: While drawing the bow, both cams must roll over at precisely the same time. Harness cable making contact with the draw stop on the bottom cam, the control cable should also be making contact with flat portion of the module on the upper cam.
Checking draw stops for bows equipped with a Hybrid Cam System: With the bow at full draw, and the split Example: if the string is to the rear of the timing mark at the top cam it should be approximately the same distance to the rear on the bottom cam.ħ. It is important that the timing marks be symmetrical from top to bottom. Timing mark location varies with bow model and draw length. Orientation marks will not line up if the string is on the “+” post or the “-“ post of the cam. Should be within a string width of being on the marks when the string is in the center post or the post with the dot. Checking static cam orientation: With the bow at rest, generally the cam orientation marks on the cam
